Trajectories of three separate particles whose initial
coordinates are:
(0.001, 0.36), (0.1, 0.5), and (0.4, 0.5)
were calculated for duration t=10,000 and for the following parameters:
Fbuoyancy
= Fcentrifugal =Fcoriolis = 0
Fbuoyancy = 0.003,
Fcentrifugal = 0, Fcoriolis = 0
Fbuoyancy = 0.01,
Fcentrifugal = 0, Fcoriolis = 0
Fbuoyancy = 0,
Fcentrifugal = 0.0001, Fcoriolis = 0
Fbuoyancy = 0,
Fcentrifugal = 0.0003, Fcoriolis = 0
Fbuoyancy = 0,
Fcentrifugal = 0.003, Fcoriolis = 0
Fbuoyancy = 0,
Fcentrifugal = 0.01, Fcoriolis = 0
Fbuoyancy = 0.001,
Fcentrifugal = 0.0001, Fcoriolis = 0
Fbuoyancy = 0.003,
Fcentrifugal = 0.0003, Fcoriolis = 0
Fbuoyancy = 0.006,
Fcentrifugal = 0.0006, Fcoriolis = 0
Fbuoyancy = 0,
Fcentrifugal = 0.0001, Fcoriolis = 0.0001
Fbuoyancy = 0,
Fcentrifugal = 0.001, Fcoriolis = 0.001
Fbuoyancy = 0,
Fcentrifugal = 0.003, Fcoriolis = 0.003
Fbuoyancy = 0,
Fcentrifugal = 0.006, Fcoriolis = 0.006
Fbuoyancy = 0.001,
Fcentrifugal = 0.0001, Fcoriolis = 0.0001
Fbuoyancy = 0.003,
Fcentrifugal = 0.0003, Fcoriolis = 0.0003
Fbuoyancy = 0.006,
Fcentrifugal = 0.0006, Fcoriolis = 0.0006
Fbuoyancy = 0.01,
Fcentrifugal = 0.001, Fcoriolis = 0.001
Trajectories of family of particles:
Fbuoyancy = 0.001, Fcentrifugal
= 0.0001, Fcoriolis = 0.0001
Particles ejected at the coordinates 0.01 < r < 0.1
with Dr = 0.001 and 0.35
< z < 0.4 with Dz
= 0.01.
Time duration t = 300
Fbuoyancy = 0.001, Fcentrifugal
= 0.0001, Fcoriolis = 0.0001
Particles ejected at the coordinates 0.01 < r < 0.1
with Dr = 0.001 and 0.35
< z < 0.47 with Dz
= 0.01.
Time duration t = 300
Fbuoyancy = 0.001, Fcentrifugal
= 0.0001, Fcoriolis = 0.0001
Particles ejected at the coordinates 0.01 < r < 0.1
with Dr = 0.001 and 0.35
< z < 0.47 with Dz
= 0.01.
Time duration t = 10,000
Fbuoyancy = 0.001, Fcentrifugal
= 0.0001, Fcoriolis = 0.0001
Particles ejected at the coordinates 0.01 < r < 0.2
with Dr = 0.001 and z
=0.36.
Time duration t = 10,000
Fbuoyancy = 0.01, Fcentrifugal
= 0.001, Fcoriolis = 0.001
Particles ejected at the coordinates 0.01 < r < 0.1
with Dr = 0.001 and z
=0.5.
Time duration t = 10,000
Fbuoyancy = 0.01, Fcentrifugal
= 0.001, Fcoriolis = 0.001
Particles ejected at the coordinates 0.2 < r < 0.3
with Dr = 0.001 and z
=0.5.
Time duration t = 10,000
Fbuoyancy = 0.01, Fcentrifugal
= 0.001, Fcoriolis = 0.001
Particles ejected at the coordinates 0.2 < r < 0.3
with Dr = 0.001 and z
=0.5.
Time duration t = 60,000
Fbuoyancy = 0.003, Fcentrifugal
= 0.0003, Fcoriolis = 0.0003
Particles ejected at the coordinates 0.01 < r < 0.2
with Dr = 0.001 and z
=0.5.
Time duration t = 10,000
|
